BAYKON INDICATORS
Powerful calibration options including electronic calibration without test weights, span calibration of non-empty tanks support easy and fast installation and service. Baykon indicators feature a10 step adaptive filter for fast settling, up to 999.999 display resolution and 1600 conversion per second.
Programming and calibration can be executed via device keys and by PC/PLC through serial ports and fieldbus. BX18 is powered by from 12-28 volt DC supply.
- BAYKON BX18, BX21
| A/D converter type | 24 bit Delta-Sigma radiometric with integral analog and digital filters |
| Conversion rate | Up to 1600 measurement values per second |
| Input sensitivity | 0.1 IV/e (non approved) |
| Analog input range | 0 mV to +18 mV ( unipolar ) ; – 18 mV to +18 mV ( bipolar ) |
| Internal resolution | up to 16 000 000 |
| External Resolution | Display resolution up to 999 999 increment |
| Scale Calibration and Functions | – |
| Calibration | Calibration is performed with or without test weights ( eCal ) |
| Digital filter | 10 steps programmable adaptive filter |
| Weighing functions | Taring, zeroing, auto zero tracking, motion detection, auto zero at power up, net indication at power on, increased resolution |
| Linearity | Within 0.0015% FS, 2 ppm/°C |
| Load cells | – |
| Excitation | 5 VDC max. 300 mA |
| Number of load cells | Up to 8 load cells 350 N or 18 load cells 1100 N in parallel |
| Connection | 4- or 6-wire technique. |
| Cable length | maximum 250 m/mm² for 6-wire connection |
| Communication | RS 232 Baud rate 1200 to 115200 baud rate, 8N1 / 7E1 / 7O1 |
| Response speed | Up to 4 ms. response delay after read/write commands RS 485. |
| Excitation | 5 VDC max. 300 mA |
| Number of load cells | Up to 8 load cells 350 N or 18 load cells 1100 N in parallel |
| Connection: | 4- or 6-wire technique. |
| Cable length | maximum 250 m/mm² for 6-wire connection |
| Communication: | RS 232 |
| Baudrate | 1200 to 115200 baud rate, 8N1 / 7E1 / 7O1 |
| Response speed | Up to 4 ms. response delay after read/write commands RS 485 |
| Baudrate | 1200 to 115200 baud rate, 8N1 / 7E1 / 7O1 |
| Response speed | to 4 ms. response delay after read/write commands |
| Max Stations | Up to 31 stations per segment |
| Analogue Output: | – |
| Voltage output | 0-5 VDC, 0-10 VDC |
| Current output | 4-20mA, 0-20mA |
| D/A Converter | 16 bit |
| Max. cable length | 300 meter |
| Max. load resistance | (current output )500 N |
| Digital Inputs and Outputs | Digital Inputs 4 optoisolated digital input, 12 to 28 VDC, 10mA Digital Outputs 6 free relay contact, 250 VAC or 30 VDC , 1A |
| DC Power supply | 12 to 28 VDC max. 300 mA |
| Environment and Enclosure | – |
| Operation temp | -10 °C to +40 °C; 85% RH max, non-condensing Enclosure Polycarbonate, DIN rail type Protection Front panel IP65. |
